7050 Aircraft Aluminum for Leading Edge Ribs
7050 aluminum is a high-strength alloy primarily used in aerospace applications, particularly for structural components that require excellent mechanical properties and stress corrosion resistance.
In aircraft, leading edge ribs are critical components that affect the structural integrity of the wings and aerodynamic efficiency. The use of 7050 aluminum in these ribs helps ensure they can withstand impacts and enhance safety.
The leading edge of the wings experiences significant forces during flight, and the strength of 7050 aluminum helps maintain the shape and performance of the wings.
The leading edge is vulnerable to impacts from debris and ice; while 7050 has good resistance to stress corrosion cracking, it may require protective coatings in highly corrosive environments.
The durability and fatigue resistance of 7050 aluminum contribute to extending the lifespan of the leading edge ribs, reducing maintenance needs, and enhancing safety.
Why Choose 7050 Aluminum for Aircraft Leading Edge Ribs
- 1. High Strength-to-Weight Ratio: 7050 aluminum achieves a good balance between strength and weight, making it an ideal choice for aircraft components, as weight reduction is critical for performance and fuel efficiency.
- 2. Durability: The excellent mechanical properties of 7050 alloy ensure that leading edge ribs can withstand the aerodynamic forces and stresses encountered during flight. Fatigue Resistance: Considering the cyclic loads experienced by aircraft structures, the fatigue resistance of 7050 aluminum is particularly beneficial for leading edge ribs, which is crucial for maintaining the integrity of the wing structure.
- 3. Weldability: Although 7050's weldability is not as good as some other aluminum alloys, it can still be connected using appropriate techniques, which is advantageous for the assembly process.
- 4. Machinability: This alloy can be machined to precise tolerances, meeting the detailed design requirements of leading edge ribs.
- 5. Thermal Stability: The 7050 alloy maintains its mechanical properties over a wide range of temperatures, which is essential for aircraft operating in varying environmental conditions.
The commonly used thickness for 7050 aluminum plates is 3-6 inches. Compared to the older, more established 7075 alloy, 7050 exhibits better toughness and corrosion resistance. Its lower sensitivity to quenching allows it to maintain its strength characteristics in thicker sections while also demonstrating good resistance to stress corrosion cracking and fracture toughness.
7050-T7451 plates have outstanding stress corrosion and peel resistance, strength, and fracture toughness, even exceeding those of the more common 7075 aerospace aluminum alloy. Welding 7050 is not recommended, as it can lead to welding cracks, porosity, and weak joints.
When using 7050 for leading edge ribs, consider factors such as weight reduction, environmental conditions, and specific load requirements to ensure optimal performance and safety in aircraft design.
The Specification of 7050 Aircraft Aluminum Plate
| Alloy | Temper | Thickness (mm) | Width(mm) |
| 7050 | T7451 | 4-260 | 1200-3800 |
| T7651 | 4-260 | 1200-3800 |
Haomei Aluminum can produce 7050 aluminum plates to the standards AMS 4050, AMS-STD-2154, EAC MS1004, EAC MS1005, and QQ-A-430, EN 3982.
7050 Aircraft Aluminum Chemical Composition
| Alloy | Si | Fe | Cu | Mn | Mg | Cr | Zn | Zr | Ti | Standard |
| 7050 | 0.12 | 0.15 | 2.0-2.6 | 0.10 | 1.9-2.6 | 0.04 | 5.7-6.7 | 0.08-0.15 | 0.06 | GB/AMS/EN |
Mechanical properties of 7050 Aircraft Aluminum plate
| Mechanical Property | Value |
| Tensile Strength | 496 MPa |
| Proof Stress | 427 Min MPa |
| Elongation | A-9 Min % |
